Cut Smarter, Safer, Faster: The Astech Automatic Saw SRA 3.0

Introduction:

In today’s competitive food processing industry, efficiency, precision, and safety are non-negotiable. That’s why Summit Process Solutions is proud to introduce the Astech Automatic Saw SRA 3.0, a next-generation cutting solution designed for both fresh and frozen bone-in or boneless products. This advanced saw combines cutting-edge technology, hygienic design, and robust engineering to deliver unmatched performance for processors across Southern Africa.

Why Choose the Automatic Saw SRA 3.0?

The SRA 3.0 is the result of years of customer feedback and Astech’s commitment to continuous innovation. By redesigning its flagship SRA1 model, Astech has produced a machine that ensures high production rates, superior precision, and maximum safety for operators — all within a more compact footprint.

How Does It Work?

At the heart of the PW-SAW is its sophisticated scanning and cutting mechanism. The machine scans each product, calculating the optimal cutting point for achieving the desired specifications. Utilizing a bandsaw for the cut, it ensures precision and consistency across all products.

Additionally, the PW-SAW incorporates load cells at the entry and exit points to gather comprehensive weight data. This data accessibility allows for process optimization and quality control, enabling food processing managers to make informed decisions.

Key Benefits of the SRA 3.0

• High Production Rate: With its optimised design, a single operator can handle two machines simultaneously, dramatically increasing throughput.

• Unmatched Precision: Thanks to constant cutting speed, advanced gripping systems, and servomotor-driven movements, you get uniform slices every time.

• Operational Versatility: The integrated program supports a wide range of cutting configurations, making it suitable for multiple products without complex changeovers.

• Superior Hygiene: Built entirely from stainless steel and food-safe plastics, the SRA 3.0 is easy to clean and maintain, reducing contamination risks.

• Enhanced Safety: Redesigned gripping systems minimize product movement during cuts while ensuring operator safety.

• Robust Durability: A reinforced chassis and stronger brackets allow the use of 19 mm blades (instead of 16 mm), extending blade life and ensuring even more accurate cuts.

Products You Can Cut with Ease

The SRA 3.0 is built for versatility. With just a change of grippers, processors can cut a wide variety of products, including:

• Poultry: chicken, turkey

• Beef: loins, cutlets, ribs

• Lamb: leg, rack, shank, skirt

• Pork: ham, ribs, loin, knuckle

• Fish: tuna, salmon, hake, blue shark

• Cheese: blocks and rounds

This flexibility makes it an indispensable tool for processors looking to streamline operations across multiple product lines.

Technical Highlights

• Machine dimensions: 2970 (4040) x 1900 (3155) x 1955 mm

• Loading area dimensions: 1000 x 650 x 200 mm

• Max cut thickness: 280 mm

• Cutting blade: 2680 x 19 mm

• Power: 8.2 kW

• Compressed air: 6 bar (10.7l per complete cycle)

Smart Add-On Options

• Cleaning System: High-pressure nozzles that remove sawdust from fresh cuts, especially useful for beef.

• Exit Conveyor: Streamlines output by discarding first and last cuts automatically and maintaining hygienic handling.

The Future of Food Processing Cuts

For food processors across Southern Africa, the Astech Automatic Saw SRA 3.0 represents a leap forward in automation, safety, and efficiency. By integrating this system into your production line with the help of Summit Process Solutions, you can:

✅ Reduce operational costs
✅ Enhance product quality
✅ Improve worker safety
✅ Maximize production output

Conclusion

At Summit Process Solutions, we specialize in tailoring equipment integration for the food processing industry. Partnering with us means not just getting world-class machinery like the SRA 3.0, but also the expertise to ensure seamless installation, customization, and ongoing support.

Take the next step

Discover how the Astech Automatic Saw SRA 3.0 can transform your operations.
Contact Summit Process Solutions today for a free consultation and system review.
